EO-1064-N 1064 nm High Energy Diode Pumped All-Solid-State Q-Switched Laser
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 1064 nm with high single pulse energy, short pulse duration and high peak power.
Applications: high energy applications, scientific research
Model #: EO-1064-N
| Wavelength (nm) | 1064±1 |
| Operating Mode | Actively |
| Single Pulse Energy (mJ) | 0.8 @1 kHz / 0.8 @5 kHz / 0.3 @20 kHz / 1.5 @3 kHz |
| Pulse Duration (ns) | <7 @1 kHz / <7 @5 kHz / <8 @20 kHz / <12 @3 kHz |
| Rep. Rate | 1 Hz-1 kHz / 1-7 kHz / 1-25 kHz / 1-3 kHz |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1% |
| M2 | <1.5 / <2 |
| Pointing Stability Over Temperature (μrad/°C) | <20 |
| Beam Divergence, Full Angle (mrad) | <3 |
| Beam Diameter (mm) | ~1 |
| Beam Height from Base Plate (mm) | 80, 563 |
| Warm-up Time (minutes) | <15 |
| Cooled Method | Air cooled or water cooled |
| Operating Temperature (℃) | 15-30 |
| Power Supply (24 VDC) | PSU-EO-N (24 V/13 A) |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # EO-1064-N
Please request a quotation for a real price and lead time.
