EO-1064-P 1064 nm Compact All-Solid-State Q-Switched Laser
$1,000,000.00
Description: Small-size all-solid-state Q-switched laser at 1064 nm with high peak power and short pulse duration.
Applications: marking, micro-machining, scientific research
Model #: EO-1064-P
| Wavelength (nm) | 1064±1 |
| Operating Mode | Actively |
| Single Pulse Energy (µJ) | 1-30 |
| Output Power (mW) | 1-150 |
| Power Stability | <5%, <3% |
| Pulse Duration (ns) | ~2.6 |
| Rep. Rate | 5 kHz |
| Beam Diameter (mm) | ≤1 |
| Beam Divergence, Full Angle (mrad) | ≤3 |
| Beam Height from Base Plate (mm) | 18 |
| Cooled Method | Conduction cooled |
| Warm-up Time (minutes) | <15 |
| Operating Voltage (VDC) | 1.64 V/5 A |
| Operating Temperature (℃) | 15-30 |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # EO-1064-P
Please request a quotation for a real price and lead time.
