213 nm LD Pumped All-Solid-Sate Sub-Nanosecond Pulsed Laser EO-213-Subnano-Hi
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 213nm has the features of high single pulse energy, short pulse duration, and high peak power.
Applications: LIF, OPO, fluorescence lifetime measurement
Model #: EO-213-Subnano-Hi-XX-YY
| Model | EO-213-Subnano-Hi |
| Wavelength | 213 nm |
| Average Power | 1-200 / 200-500 mW |
| Repetition Rate | 100 Hz-10 kHz |
| Power Stability | <5% |
| Warm-Up Time | < 15 min. |
| Operation Mode | Pulsed |
| Pulse Width | <1.5 / ~2 ns |
| Single Pulse Energy | 1-40 / 40-100 µJ |
| Beam Diameter at the Aperture | ~1.5 mm |
| Beam Divergence, Full Angle | ≤3 mrad |
| Cooling Method | Air cooled or water cooled |
| Operating Voltage (VDC) | 24V/21A |
| Operating Temperature | 15-30 ℃ |
| Expected Lifetime | >10000 (hours) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # EO-213-Subnano-Hi
Please request a quotation for a real price and lead time.
