266 nm LD Pumped All-Solid-Sate Passively Q-switched Pulsed Laser EO-266-P-Subnano
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 266 nm has the features of high single pulse energy, short pulse duration and high peak power.
Applications: Lidar, biomedicine, environmental monitoring, scientific research
Model #: EO-266-P-Subnano
| Wavelength | 266±1 |
| Operation Mode | Passively Q-switched |
| Single Pulse Energy | 1-110 @2kHz |
| Pulse Width | <1 |
| Repetition Rate | 500Hz, 1kHz, 2kHz (optional) |
| Energy Stability | <5% |
| Transverse Mode | TEM00 |
| M2 | ≤1.5 |
| Beam Divergence, Full Angle | <3 |
| Beam Diameter | ~3 |
| Warm-Up Time | <15 |
| Beam Height from Base Plate | 66 |
| Cooling Method | Air cooled |
| Operating Temperature | 15-30 |
| Power Supply (110 - 220 VAC) | PSU-EO-P-Subnano |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # EO-266-P-Subnano
Please request a quotation for a real price and lead time.
