266 nm LD Pumped All-Solid-Sate Electric-optic Q-switched Pulsed Laser EO-266-Subnano-Hi
$1,000,000.00
Description: High energy diode pumped all solid state Q-switched laser at 266 nm has the features of high single pulse energy, short pulse duration and high peak power.
Applications: differential absorption lidar, LIF, precision drilling
Model #: EO-266-Subnano-Hi
| Wavelength | 266±1 |
| Operation Mode | Electric-optic Q-switched |
| Single Pulse Energy | 1-200 @5kHz / 200-500 @5kHz |
| Average Power | 1mW-1W @5kHz / 1-2.5W @5kHz |
| Power Stability | <5% |
| Pulse Width | <1.5 @5kHz / ~2 @5kHz |
| Repetition Rate | 100Hz-10kHz |
| Beam Diameter | ~1.5 |
| Beam Divergence, Full Angle | ≤3 |
| Cooling Method | Air cooled or water cooled |
| Warm-Up Time | <15 |
| Operating Voltage | 24V/21A |
| Operating Temperature | 15-30 |
| Expected Lifetime | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # EO-266-Subnano-Hi
Please request a quotation for a real price and lead time.
