EO-XS-1064 1064 nm LD Pumped All-Solid-State EOM Q-Switched Laser
$1,000,000.00
Description: All solid state EOM Q-switched laser at 1064 nm with high peak power, high repetition rate and short pulse duration.
Applications: marking, carving, measurement, research and so on
Model #: EO-XS-1064
| Wavelength (nm) | 1064±1 |
| Operating Mode | Actively |
| Average Power (W) | 1-10 (10 W @50 kHz) |
| Single Pulse Energy (µJ) | 1-200 (200 µJ @50 kHz) |
| Rep. Rate | 10-100 kHz |
| Pulse Duration (ns) | ~4 @50 kHz |
| Peak Power (kW) | 1-50 |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1% |
| Transverse Mode | TEM00 |
| Beam Divergence, Full Angle (mrad) | <2 |
| Beam Diameter at the Aperture (1/e2, mm) | ~1.0 |
| M2 | <1.2 |
| Beam Height from Base Plate (mm) | 80 |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Air cooled |
| Operating Temperature (°C) | 10-35 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # EO-XS-1064
Please request a quotation for a real price and lead time.
