EO-XS-1342 1342 nm EOM Q-Switched Solid-State Laser
$1,000,000.00
Description: All-solid-state EOM Q-switched laser at 1342 nm featuring high peak power, high repetition rate and short pulse duration.
Applications: marking, carving, measurement, research
Model #: EO-XS-1342
| Wavelength (nm) | 1342±1 |
| Operating Mode | Actively Q-switched |
| Average Power (W) | 1-3 (3 W @10 kHz) |
| Single Pulse Energy (µJ) | 1-300 (300 µJ @10 kHz) |
| Repetition Rate | 10 kHz |
| Pulse Duration (ns) | ~4 @10 kHz |
| Peak Power (kW) | 1-75 (75 kW @10 kHz) |
| Average Power Stability (rms, 4 hours ± 3°C) | <5%, <3% |
| Warm-up Time (minutes) | <10 |
| Beam Divergence, Full Angle (mrad) | <3 |
| Beam Diameter at the Aperture (1/e2, mm) | ~2 |
| Polarization Ratio | >100:1 |
| Beam Height from Base Plate (mm) | ~80 |
| Operating Temperature (°C) | 10-35 |
| Power Supply | PSU-XS (24 VDC) |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # EO-XS-1342
Please request a quotation for a real price and lead time.
