EO-XS-2600-4410 2600-4410 nm Q-Switched Mid-Infrared Laser
$1,000,000.00
Description: LD pumped all-solid-state Q-switched laser covering 2600-4410 nm with high peak power, high repetition rate and short pulse duration. Any wavelength range in the list can be ordered.
Applications: medical treatment, scientific research, etc.
Model #: EO-XS-2600-4410
| Wavelength (nm) | 2600-2850 / 2930-3150 / 3200-3390 / 3400-3600 / 3640-3770 / 3800-3930 / 3950-4070 / 4100-4200 / 4240-4320 / 4350-4410 |
| Operating Mode | Actively Q-switched |
| Average Power (mW) | >1000 @ 30 kHz |
| Power Stability (rms, 4 hours ± 3°C) | <5%, <3% |
| Pulse Duration (ns) | ~15 @ 30 kHz |
| Repetition Rate | 30-50 kHz |
| Single Pulse Energy (µJ) | 1-33.3 |
| Beam Divergence, Full Angle (mrad) | <5 |
| Beam Diameter at the Aperture (1/e2, mm) | ~7 |
| Beam Height from Base Plate (mm) | 110 |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Air cooled |
| Operating Temperature (°C) | 10-35 |
| Power Supply (100-240 VAC) | PSU-AOM (3U) |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # EO-XS-2600-4410
Please request a quotation for a real price and lead time.
