FC-D-976 976 nm Raman Spectroscopy Diode Laser Module
$1,000,000.00
Description: With narrow spectral bandwidth, spectral purity and a high level of wavelength stability, FC-D-976 laser module is designed specially for Raman spectroscopy, which has integrated laser drivers and thermoelectric coolers together, its compact dimension make it suitable for OEM.
Applications: Raman spectroscopy
Model #: FC-D-976
| Model | FC-D-976 |
| Model | FC-D-976 (Spectrum Stabilized for Raman Spectroscopy) |
| Central Wavelength (nm) | 976±5 |
| Spectral Line Width (nm) | 0.1, (0.06 optional) |
| Operating Mode | CW |
| Fiber Core Diameter | 100µm, 0.22 NA |
| Fiber Connector | SMA905, FC/PC optional |
| Fiber Length¹ | 1m |
| Fiber Jacket | Metal, PVC optional |
| Output Power After Fiber (mW)² | 1-450 |
| Power Stability (rms, 4 hours ±3°C) | <3%, <2%, <1% |
| Frequency Shift (pm, over ±2°C and 2 hours) | <20 |
| Noise of Amplitude (rms, 20Hz-20MHz) | <1% |
| Warm-Up Time (minutes) | <5 |
| Cooled Method | Air cooled |
| Operating Temperature (℃) | 20-30 |
| Operating Voltage (VDC) | 5V/6A |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FC-D-976
Please request a quotation for a real price and lead time.
