FC-W-405H-II 405 nm High Power Fiber Coupling Diode Laser System
$1,000,000.00
Description: The FC-W-405H-II series (Fiber Coupling Laser System) has integrated laser diode, fiber coupling optics, laser power supply, LD current and temperature control in ONE box.
Applications: industrial, medical, biomedical
Model #: FC-W-405H-II
| Model | FC-W-405H-II |
| Wavelength (nm) | 405±5 |
| Operating Mode | CW |
| Output Power (W) @ after fiber | 30 / 50 / 100 |
| Fiber Core Diameter (µm) | 400, 0.22NA / 600, 0.22NA |
| Fiber Connector | SMA905, FC/PC optional |
| Fiber Length¹ | 2m |
| Power Stability (rms, 4 hours±3℃) | <2%, <1% |
| Cooled Method | Water cooled |
| Operating Voltage (VDC) | DC24 / DC24 / AC220 |
| Operating Temperature (℃) | 0-30 |
| Modulation Option | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FC-W-405H-II
Please request a quotation for a real price and lead time.
