FC-W-638-525-2.9W Multi-Wavelength Fiber-Coupled Laser System
$1,000,000.00
Description: The FC-W-638/525 series (Fiber Coupling Laser System) have integrated laser diode, fiber coupling optics, laser power supply, LD current and temperature control in ONE box. Its compact dimension and convenient functions, such as power adjustment, temperature control, LED display etc, make it very suitable for scientific research, industrial and medical applications.
Applications: scientific research, industrial and medical applications
Model #: FC-W-638-525-2.9W
| Wavelength (nm) | ['638±10', '525±10'] |
| Output Power (W) @ after 200µm fiber | ['1.6', '1.3'] |
| Operating Mode | ['CW'] |
| Cooling Method | ['Air cooled'] |
| Fiber Core Diameter (µm) | ['200, 400, 0.22NA'] |
| Fiber Connector | ['SMA905, FC/PC optional'] |
| Fiber Length | ['1 m'] |
| Fiber Jacket | ['PVC, Metal optional'] |
| Power Stability (rms, 4 hours ±3℃) | ['<2%, <1%'] |
| Warm-up Time (minutes) | ['<5'] |
| Operating Temperature (℃) | ['0-30'] |
| Operating Voltage (VAC) | ['100-240'] |
| Modulation Option | ['DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional'] |
| Expected Lifetime (hours) | ['>10000'] |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FC-W-638-525-2.9W
Please request a quotation for a real price and lead time.
