FC-W-878.6H 878.6 nm High Power Fiber-Coupled Diode Laser System
$1,000,000.00
Description: High power fiber coupling diode laser system at 878.6 nm. Integrates laser diode, fiber coupling optics, laser power supply, LD current and temperature control in ONE box. Compact dimension and convenient functions (power adjustment, temperature control, LED display) make it very suitable for pumping, scientific research, industrial and medical applications.
Applications: pumping, scientific research, industrial and medical applications
Model #: FC-W-878.6H
| Model | FC-W-878.6H |
| Wavelength (nm) | 878.6 |
| Operating Mode | CW |
| After Fiber Output Power (W) | 50-150 |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1%, (<0.5% optional) |
| Red Pilot Light | Available on request |
| Fiber Core Diameter | 400 µm, 0.22 NA |
| Fiber Connector | SMA905, FC/PC optional |
| Fiber Length | 2 m |
| Fiber Jacket | Metal, PVC optional |
| LED Display | Diode current |
| Operating Temperature (°C) | 10-40 |
| Modulation Option | DC-1 kHz, 1 kHz-10 kHz, 10 kHz-30 kHz, 30 kHz-100 kHz optional; TTL and Analog optional |
| Operating Voltage (VAC) | 100-240 |
| Cooling Method | Air cooled |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FC-W-878.6H
Please request a quotation for a real price and lead time.
