FL-1014-SLM-Seed 1014 nm Single Frequency Mode Seed Fiber Laser
$1,000,000.00
Description: Single frequency mode seed fiber laser with selectable wavelength range 1014-1120nm. Features ultra-narrow linewidth (<10 kHz), single-mode PM fiber output and low relative intensity noise.
Applications: seeding fiber amplifiers, spectroscopy, interferometry, quantum optics
Model #: FL-1014-SLM-Seed
| Model | FL-1014-SLM-Seed |
| Selectable Wavelength Range (nm) | 1014-1120 |
| Typical Wavelength (nm) | 1014, 1018, 1027, 1030, 1040, …, 1120 |
| Operating Mode | CW |
| Output Power (mW)¹ | 1-50 (1-5 @1120nm) |
| Power Stability (rms, 4 hours ±3°C) | <3%, <2%, <1% |
| Temperature Tuning Range (nm) | >0.5 |
| Transverse Mode | TEM00 |
| Output Mode | Single-mode PM fiber |
| Numerical Aperture | 0.14NA |
| Fiber Connector² | FC/APC |
| Fiber Length (m)³ | 1 |
| Fiber Jacket | PVC, Metal optional |
| Spectral Linewidth (kHz) | <10, <5 (<100 @1120nm) |
| Polarization Ratio (dB) | >20, after PM fiber |
| M² | <1.05 |
| Relative Intensity Noise (rms, 20Hz-20MHz) | <0.1%, <0.05%, (<0.03% optional) |
| Relative Intensity Noise (dBc/Hz) | <-140 (10MHz) |
| Peak Intensity Noise (dBc/Hz) | <-130 |
| Relaxation Oscillation Peak Frequency (MHz) | 2-3 |
| PZT Tuning Range (GHz) | >3 |
| PZT Tuning Bandwidth (kHz) | >5 |
| Cooled Method | Conduction cooled |
| Operating Temperature (℃) | 15-30 |
| Power Dissipation (W) | 12 |
| Operating Voltage (VDC) | 12V/11.5A |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-1014-SLM-Seed
Please request a quotation for a real price and lead time.
