FL-1018-SLM 1018 nm Single Longitudinal Mode Fiber Laser
$1,000,000.00
Description: Single longitudinal mode (SLM) fiber laser at 1018nm. Features ultra-narrow linewidth (<10 kHz), PZT tuning and high power stability.
Applications: interferometry, spectroscopy, cold-atom physics, quantum optics
Model #: FL-1018-SLM
| Model | FL-1018-SLM |
| Wavelength (nm) | 1018±1 |
| Operating Mode | CW |
| Output Power (W)¹ | 1-10 |
| Power Stability (rms, 4 hours ±3°C) | <2%, <1%, <0.5% |
| Transverse Mode | TEM00 |
| Longitudinal Mode | SLM |
| Current Adjustment Range | 1-100% |
| Spectral Linewidth (kHz) | <10 |
| Temperature Tuning Range (nm) | >0.4 |
| PZT Tuning Range (GHz) | >3 |
| PZT Tuning Bandwidth (kHz) | >5 |
| Relative Intensity Noise (rms, 20Hz-20MHz) | <0.3%, <0.1%, (<0.05% optional) |
| Frequency Shift (MHz, over ±2°C and 8 hours) | <±200 |
| M² | <1.1 |
| Fiber Connector² | FC/APC, Collimator optional |
| Fiber Length (m)³ | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm)⁴ | 4±1 (Collimator output) |
| Pointing Stability (µrad) | <5 |
| Polarization Ratio (dB) | >15, after PM fiber |
| Warm-Up Time (minutes) | <30 |
| Cooled Method⁵ | Air cooled or Water cooled |
| Operating Temperature (℃) | 15-30 |
| Power Supply (VAC) | 110/220VAC |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-1018-SLM
Please request a quotation for a real price and lead time.
