FL-1030-CW 1030 nm High Power All Fiber CW Laser
$1,000,000.00
Description: High power air cooled all fiber CW laser at 1030nm is made features of ultra compact, long lifetime, low cost and easy operating, which is widely used in laser radar, life science, material processing, microelectronics, scientific research, etc.
Applications: laser radar, life science, material processing, microelectronics, scientific research
Model #: FL-1030-CW
| Model | FL-1030-CW |
| Wavelength (nm) | 1030±2 |
| Operating Mode | CW or Modulated |
| Output Power (W)¹ | 1-100 |
| Transverse Mode | TEM00 @1-20W, Multimode @>20W |
| Power Stability (rms, 4 hours ±3℃) | <3%, <2%, <1% |
| Fiber Connector² | FC/APC, Collimator optional |
| Fiber Length (m)³ | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm)⁴ | 4±1 (Collimator output) |
| M² | <1.2 (<50W), <1.5 (>50W) |
| Polarization State | Random |
| Warm-Up Time (minutes) | <15 |
| Operating Temperature (℃) | 15-35 |
| Cooled Method | Air cooled |
| Power Supply | DC 12V (1-10W) / AC 220V (10-100W) |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-1030-CW
Please request a quotation for a real price and lead time.
