FL-1030-LN-L 1030 nm Low Noise Fiber Laser
$1,000,000.00
Description: Low noise fiber laser at 1030nm. Features single longitudinal mode, ultra-low relative intensity noise (<0.1%) and high power stability.
Applications: interferometry, spectroscopy, sensing, quantum optics
Model #: FL-1030-LN-L
| Model | FL-1030-LN-L |
| Wavelength (nm) | 1030±1 |
| Operating Mode | CW |
| Output Power (W)¹ | 1-10 |
| Power Stability (rms, 4 hours ±3°C) | <2%, <1%, <0.5% |
| Transverse Mode | TEM00 |
| Longitudinal Mode | SLM |
| Current Adjustment Range | 1-100% |
| Spectral Linewidth (nm) | <0.004 |
| Relative Intensity Noise (rms, 20Hz-20MHz) | <0.1%, <0.05% |
| Frequency Shift (MHz, over ±2°C and 8 hours) | <±200 |
| M² | <1.1 |
| Fiber Connector² | FC/APC, Collimator optional |
| Fiber Length (m)³ | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm)⁴ | 4±1 (Collimator output) |
| Pointing Stability (µrad) | <5 |
| Polarization Ratio (dB) | >15, after PM fiber |
| Warm-Up Time (minutes) | <30 |
| Cooled Method | Air cooled or Water cooled |
| Operating Temperature (℃) | 15-30 |
| Power Supply (VAC) | 110/220VAC |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-1030-LN-L
Please request a quotation for a real price and lead time.
