FL-1030-Nano 1030 nm High Frequency All Fiber Pulsed Laser
$1,000,000.00
Description: High frequency all fiber pulsed laser at 1030nm is made features of high output power stability, good beam profile, ultra compact, long lifetime, low cost and easy operating, which is widely used in laser radar, life science, material processing, microelectronics, scientific research, etc.
Applications: laser radar, life science, material processing, microelectronics, scientific research
Model #: FL-1030-Nano
| Model | FL-1030-Nano |
| Wavelength (nm) | 1030±1 |
| Operating Mode | Pulsed |
| Average Power (W)¹ | 0.5-10 |
| Power Stability (rms, 4 hours ±3℃) | <3%, <2% |
| Pulse Duration (ns)² | 0.5-5 / 5-100 / 100-250 |
| Repetition Rate | 100kHz-1MHz (adjustable) |
| M² | <1.8 |
| Fiber Connector³ | FC/APC, Collimator optional |
| Fiber Length (m)⁴ | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm)⁵ | 4±1 (Collimator output) |
| Polarization Ratio (dB) | Random / >15 |
| Warm-Up Time (minutes) | <15 |
| Operating Temperature (℃) | 15-35 |
| Cooled Method | Air cooled |
| Power Supply (VAC) | 110/220VAC |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-1030-Nano
Please request a quotation for a real price and lead time.
