FL-1030-Pico 1030 nm Picosecond All Fiber Pulsed Laser
$1,000,000.00
Description: Picosecond all fiber pulsed laser at 1030nm is made features of high output power stability, good beam profile, ultra compact, long lifetime, cost-effectiveness and easy operating, which is widely used in laser radar, precision marking, precision drilling, life science, precision etching, microelectronics, scientific research, etc.
Applications: laser radar, precision marking, precision drilling, life science, precision etching, microelectronics, scientific research
Model #: FL-1030-Pico
| Model | FL-1030-Pico |
| Wavelength (nm) | 1030±1 |
| Operating Mode | Pulsed |
| Average Power (mW)¹ | 10-100 mW / 100 mW-5 W |
| Power Stability (rms, 4 hours ±3℃) | <3%, <2% |
| Pulse Duration (ps)² | 100-900 |
| M² | <1.2 / <1.5 |
| Repetition Rate³ | 0.1-20MHz (fixed or variable) |
| Fiber Connector⁴ | FC/APC, Collimator optional |
| Fiber Length (m)⁵ | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm)⁶ | 4±1 (Collimator output) |
| Polarization Ratio (dB) | Random / >15 |
| Warm-Up Time (minutes) | <15 |
| Operating Temperature (℃) | 15-35 |
| Cooled Method | Air cooled |
| Power Supply (VAC) | 110/220VAC |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-1030-Pico
Please request a quotation for a real price and lead time.
