FL-1030-PS 1030 nm Mode-Locked All Fiber Pulsed Laser
$1,000,000.00
Description: Mode-locked all fiber pulsed laser at 1030nm with SESAM technique is made features of high output power stability, good beam profile, ultra compact, long lifetime, cost-effectiveness and easy operating, which is widely used in laser radar, precision marking, precision drilling, life science, precision etching, microelectronics, scientific research, etc.
Applications: laser radar, precision marking, precision drilling, life science, precision etching, microelectronics, scientific research
Model #: FL-1030-PS
| Model | FL-1030-PS |
| Wavelength (nm) | 1030±1 |
| Operating Mode | Passively |
| Average Power (mW) | 1-100 mW / 100 mW-2 W |
| Power Stability (rms, 4 hours ±3℃) | <3%, <2%, <1% / <3%, <1%, <0.5% |
| Pulse Duration (ps) | <10 |
| M² | <1.2 / <1.5 |
| Repetition Rate¹ | 20-50MHz |
| Fiber Connector² | FC/APC, Collimator optional |
| Fiber Length (m)³ | 1 |
| Fiber Jacket | PVC, Metal optional |
| Warm-Up Time (minutes) | <15 |
| Operating Temperature (℃) | 15-35 |
| Cooled Method | Air cooled |
| Power Supply (VAC) | 110/220VAC |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-1030-PS
Please request a quotation for a real price and lead time.
