FL-1053-LN-H 1053 nm High Power Low-Noise Fiber Laser
$1,000,000.00
Description: High power low-noise fiber laser at 1053 nm with ultra-stable output power, excellent beam quality and extremely low relative intensity noise (RIN).
Applications: wafer inspection, optical trap, holographic imaging, pumping source and scientific research, etc.
Model #: FL-1053-LN-H
| Selectable Wavelength Range (nm) | 1014-1060 |
| Typical Wavelength (nm) | 1053 |
| Operating Mode | CW |
| Output Power (W) | 10-35 |
| Power Stability (rms, 4 hours ± 3°C) | <1%, <0.5% |
| Transverse Mode | TEM00 |
| Longitudinal Mode | SLM |
| Current Adjustment Range | 1-100% |
| Spectral Linewidth (nm) | <0.004 |
| Relative Intensity Noise (rms, 10 Hz-3 MHz) | <0.1%, <0.05% |
| Frequency Shift (MHz, over ±2°C and 8 hours) | <±200 |
| M2 | TEM00, <1.1 |
| Fiber Connector | Collimator |
| Fiber Length (m) | <3 |
| Fiber Jacket | Metal |
| Beam Diameter (mm) | 4±1 (Collimator output) |
| Pointing Stability (μrad) | <5 |
| Polarization Ratio (dB) | >15, after PM fiber |
| Cooling Method | Air cooled or Water cooled |
| Operating Temperature (℃) | 15-30 |
| Power Supply (VAC) | 110/220 VAC |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-1053-LN-H
Please request a quotation for a real price and lead time.
