FL-1053-SLM 1053 nm Single Longitudinal Mode Fiber Laser
$1,000,000.00
Description: High-power, single-longitudinal-mode, PM fiber laser at 1053 nm comprising a seed laser and an amplifier. Optimized for narrow linewidth operation and applications requiring higher optical power.
Applications: frequency doubling source, mid-infrared pump laser, neutron source of solid state laser, biomedical research, etc.
Model #: FL-1053-SLM
| Wavelength (nm) | 1053±1 |
| Operating Mode | CW |
| Output Power (W) | 1-10 |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1%, <0.5% |
| Transverse Mode | TEM00 |
| Longitudinal Mode | SLM |
| Current Adjustment Range | 1-100% |
| Spectral Linewidth (kHz) | <10 |
| Temperature Tuning Range (nm) | >0.4 |
| PZT Tuning Range (GHz) | >3 |
| PZT Tuning Bandwidth (kHz) | >5 |
| Relative Intensity Noise (rms, 10 Hz-3 MHz) | <0.3%, <0.1%, (<0.05% optional) |
| Frequency Shift (MHz, over ±2°C and 8 hours) | <±200 |
| M2 | <1.1 |
| Fiber Connector | FC/APC, Collimator optional |
| Fiber Length (m) | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm) | 4±1 (Collimator output) |
| Pointing Stability (μrad) | <5 |
| Polarization Ratio (dB) | >15, after PM fiber |
| Warm-up Time (minutes) | <30 |
| Cooling Method | Air cooled or Water cooled |
| Operating Temperature (℃) | 15-30 |
| Power Supply (VAC) | 110/220 VAC |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-1053-SLM
Please request a quotation for a real price and lead time.
