FL-1550-AO 1550 nm All Fiber Pulsed Laser
$1,000,000.00
Description: All fiber pulsed laser at 1550 nm featuring ultra compact design, long lifetime, low cost and easy operating.
Applications: laser radar, laser ranging, telemetry, medical cosmetology, holography spectrum analysis, scientific experiment, optical instrument, interference, security
Model #: FL-1550-AO
| Wavelength (nm) | 1550±1 |
| Operating Mode | Pulsed |
| Single Pulse Energy (µJ) | 1-20 |
| Energy Stability (rms) | <3%, <2% |
| Pulse Width (ns) | 0.5-5 / 5-50 |
| Rep. Rate | 1-200 Hz (adjustable) |
| Transverse Mode | TEM00 |
| M2 | <1.1 |
| Fiber Connector | FC/APC, Collimator optional |
| Fiber Length (m) | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm) | 4±1 (Collimator output) |
| Polarization State (dB) | Random / >15 |
| Warm-up Time (minutes) | <15 |
| Cooled Method | Air cooled |
| Operating Temperature (°C) | 15-35 |
| Operating Voltage (VAC/VDC) | 110/220VAC or 12V/11.5A |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-1550-AO
Please request a quotation for a real price and lead time.
