FL-1550-Pico 1550 nm Picosecond All Fiber Pulsed Laser
$1,000,000.00
Description: Picosecond all fiber pulsed laser at 1550 nm featuring high output power stability, good beam profile, ultra compact design and long lifetime.
Applications: laser radar, precision marking, precision drilling, life science, precision etching, microelectronics, scientific research
Model #: FL-1550-Pico
| Wavelength (nm) | 1550±1 |
| Operating Mode | Pulsed |
| Average Power (mW) | 100-1000 |
| Power Stability (rms, 4 hours ± 3°C) | <3%, <2% |
| Pulse Duration (ps) | 100-900 |
| Rep. Rate | 100 kHz-20 MHz |
| M2 | <1.2 |
| Fiber Connector | FC/APC, Collimator optional |
| Fiber Length (m) | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm) | 4±1 (Collimator output) |
| Polarization Ratio (dB) | Random / >15 |
| Warm-up Time (minutes) | <15 |
| Cooled Method | Air cooled |
| Operating Temperature (°C) | 15-35 |
| Operating Voltage (VDC) | 12V/11.5A |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-1550-Pico
Please request a quotation for a real price and lead time.
