FL-507-LN-L 507 nm Low-Noise Fiber Laser
$1,000,000.00
Description: The 507nm low-noise laser has the characteristics of ultra-stable output power, narrow line width, excellent beam quality and extremely low relative intensity noise (RIN).
Applications: optical lattices, atomic cooling and scientific research
Model #: FL-507-LN-L
| Model | FL-507-LN-L |
| Wavelength (nm) | 507±1 |
| Operating Mode | CW |
| Free Space Output Power (mW) | 1-100 / 100-200 / 200-500 |
| Fiber Coupled Output Power (mW) | 1-50 / 50-100 / 100-250 |
| Power Stability (rms, 4 hours ±3°C) | <2%, <1% |
| Longitudinal Mode | Single |
| Current Adjustment Range | 1-100% |
| Spectral Linewidth (nm) | <0.002 |
| Relative Intensity Noise (DC-3MHz) | <0.1%, <0.05% |
| Frequency Shift (MHz, over ±2°C and 8 hours) | <±200 |
| M² | TEM00, <1.1 |
| Fiber Core | 0.14 NA |
| Fiber Connector¹ | FC/APC |
| Fiber Length (m)² | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm) | ~1 @ free space output |
| Pointing Stability over Temperature (µrad/°C) | <50 |
| Polarization Ratio (dB) | >15, Horizontal (Vertical optional) |
| Warm-Up Time (minutes) | <30 |
| Cooled Method | Air cooled / Water cooled (optional) |
| Operating Temperature (℃) | 15-30 |
| Operating Voltage (VAC) | 110/220 |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-507-LN-L
Please request a quotation for a real price and lead time.
