FL-513-SLM 513 nm Single Longitudinal Mode Fiber Laser
$1,000,000.00
Description: The high-power, single-longitudinal-mode, PM fiber laser comprises a seed laser and an amplifier. It is optimized for narrow linewidth operation and applications that require higher optical power.
Applications: laser cooling, trapping, optical lattice, pump laser for OPO
Model #: FL-513-SLM
| Model | FL-513-SLM |
| Wavelength (nm) | 513±1 |
| Operating Mode | CW |
| Free Space Output Power (mW)¹ | 1-1000 |
| Fiber Coupled Output Power (mW) | 1-500 |
| Power Stability (rms, 4 hours ±3°C) | <2%, <1% |
| Transverse Mode | TEM00 |
| Longitudinal Mode | SLM |
| Current Adjustment Range | 1-100% |
| Spectral Linewidth (kHz) | <40 |
| Temperature Tuning Range (nm) | >0.2 |
| PZT Tuning Range (GHz) | >5 |
| PZT Tuning Bandwidth (kHz) | >5 |
| Relative Intensity Noise (rms, 10Hz-3MHz) | <0.3%, <0.1%, (<0.05% optional) |
| Frequency Shift (MHz, over ±2°C and 8 hours) | <±200 |
| M² | <1.1 |
| Numerical Aperture | 0.12 NA |
| Fiber Connector² | FC/APC |
| Fiber Length (m)³ | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm) | ~1 @ free space output |
| Pointing Stability (µrad) | <15 |
| Polarization Ratio (dB) | >15, Horizontal (Vertical optional) |
| Warm-Up Time (minutes) | <30 |
| Cooled Method | Air cooled or Water cooled |
| Operating Temperature (℃) | 15-30 |
| Operating Voltage (VAC) | 110/220 |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-513-SLM
Please request a quotation for a real price and lead time.
