FL-515-Nano 515 nm High Frequency All-Fiber Pulsed Laser
$1,000,000.00
Description: High frequency all fiber pulsed laser at 515nm is made features of high output power stability, good beam profile, ultra compact, long lifetime, low cost and easy operating.
Applications: laser drilling, glass engraving, scientific research
Model #: FL-515-Nano
| Model | FL-515-Nano |
| Wavelength (nm) | 515±1 |
| Operating Mode | Pulsed |
| Output Power (mW)¹ | 1-1000 |
| Power Stability (rms, 4 hours ±3°C) | <3%, <2% |
| Pulse Duration (ns)² | 0.5-50 |
| M² | <1.8 |
| Repetition Rate³ | 100 kHz - 1 MHz |
| Polarization Ratio (dB) | >15, Horizontal (Vertical optional) |
| Warm-Up Time (minutes) | <15 |
| Delivery Fiber Length (cm) | 60 |
| Cooled Method | Air cooled |
| Operating Temperature (℃) | 15-35 |
| Operating Voltage (VDC) | 12V/11.5A |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-515-Nano
Please request a quotation for a real price and lead time.
