FL-515-PS 515 nm Mode-Locked All-Fiber Pulsed Laser
$1,000,000.00
Description: Mode-locked all fiber pulsed laser at 515nm with SESAM technique is made features of high output power stability, good beam profile, ultra compact, long lifetime, cost-effectiveness and easy operating.
Applications: TCSPC, picosecond processing, scientific research
Model #: FL-515-PS
| Model | FL-515-PS |
| Wavelength (nm) | 515±1 |
| Operating Mode | Passively |
| Output Power (mW) | 1-200 |
| Power Stability (rms, over 4 hours) | <3%, <2% |
| Pulse Duration (ps) | <10 |
| M² | <1.5 |
| Repetition Rate¹ | 20-50 MHz |
| Polarization Ratio (dB) | >15, Horizontal (Vertical optional) |
| Warm-Up Time (minutes) | <15 |
| Beam Height from Base Plate (mm) | 30 |
| Delivery Fiber Length (cm) | 60 |
| Cooled Method | Air cooled |
| Operating Temperature (℃) | 15-35 |
| Operating Voltage (VDC) | 12V/11.5A |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-515-PS
Please request a quotation for a real price and lead time.
