FL-852-SLM 852 nm Single Longitudinal Mode Fiber Laser
$1,000,000.00
Description: The high-power, single-longitudinal-mode fiber laser comprises a seed laser, an amplifier, and a nonlinear module. It is specifically designed for applications requiring high power stability and narrow linewidth, which has been designed for operation in quantum information and computing, quantum precision measurement, cold atom physics and high-resolution spectroscopy.
Applications: quantum information and computing, quantum precision measurement, cold atom physics, high-resolution spectroscopy
Model #: FL-852-SLM
| Model | FL-852-SLM |
| Wavelength (nm) | 852±1 |
| Operating Mode | CW |
| Free Space Output Power (mW)¹ | 1-500 / 1-1000 |
| Power Stability (rms, 4 hours ±3℃) | <2%, <1% |
| Transverse Mode | TEM00 |
| Longitudinal Mode | SLM |
| Current Adjustment Range | 1-100% |
| Spectral Linewidth (kHz) | <50 |
| Temperature Tuning Range (nm) | >0.15 |
| PZT Tuning Range (GHz) | >3 |
| PZT Tuning Bandwidth (kHz) | >5 |
| Relative Intensity Noise (rms, 10Hz-3MHz) | <0.3%, <0.1% |
| Frequency Shift (MHz, over ±2℃ and 8 hours) | <±200 |
| M² | <1.1 |
| Fiber Length (m)² | 1.5-2 |
| Beam Diameter (mm) | ~1@free space output |
| Pointing Stability (µrad) | <15 |
| Polarization Ratio (dB) | >15, Horizontal (Vertical optional) |
| Warm-Up Time (minutes) | <30 |
| Cooled Method³ | Air cooled / Water cooled |
| Operating Temperature (℃) | 15-30 |
| Operating Voltage (VAC) | 110/220V |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-852-SLM
Please request a quotation for a real price and lead time.
