FL-LN-FA (1014-1120) 1014 nm Low Noise Fiber Amplifier
$1,000,000.00
Description: Low noise fiber amplifier with selectable wavelength range 1014-1030nm. Features high output power up to 10W, low excess relative intensity noise (<0.03%) and PM fiber output.
Applications: amplification of narrow linewidth seed lasers, interferometry, spectroscopy
Model #: FL-LN-FA (1014-1120)
| Model | FL-LN-FA (1014-1120) |
| Wavelength Range (nm) | 1014-1030 |
| Typical Wavelength (nm) | 1018, 1030, 1064 |
| Output Power (W)¹ | 1-10 |
| Operating Mode | CW |
| Power Stability (rms, 4 hours ±3°C) | <2%, <1%, <0.5% |
| Power Tuning Range | 1~100% |
| Transverse Mode | TEM00 |
| M² | <1.1 (Power ≤5W) / <1.3 (Power >5W) |
| Excess Relative Intensity Noise | <0.03% |
| Fiber Connector² | FC/APC, Collimator optional |
| Fiber Length (m)³ | 1 |
| Fiber Jacket | PVC, Metal optional |
| Beam Diameter (mm)⁴ | 4±1 (Collimator output) |
| Pointing Stability (µrad) | <5 |
| Polarization Ratio (dB) | >15, after PM fiber |
| Seed Laser Input Power (mW) | ≥10, Single mode PM fiber, FC/APC |
| Seed Laser Input Isolation (dB) | >20 |
| Output Laser Isolation (dB) | >20 |
| Cooled Method | Air cooled (≤30W) or Water cooled |
| Operating Temperature (℃) | 15-30 |
| Power Supply (VAC) | 110/220VAC |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FL-LN-FA (1014-1120)
Please request a quotation for a real price and lead time.
