FS-H-780A 780 nm Femtosecond Fiber Laser
$1,000,000.00
Description: Femtosecond fiber laser at 780nm with ultra-short pulse duration, used in scientific research.
Applications: scientific research, microscopy, THz generation
Model #: FS-H-780A
| Model | FS-H-780A |
| Wavelength (nm) | 780±15 |
| Operating Mode | Pulsed |
| Average Power (mW)¹ | 1-50 |
| Single Pulse Energy (nJ) | 0.1-0.6 |
| Repetition Rate (MHz) | 80±2 |
| Pulse Duration (fs) | <100 |
| Peak Power (kW) | 1-6 |
| Average Power Stability (rms, 4 hours ±3°C) | <2%, <1% |
| Warm-Up Time (minutes) | <10 |
| Transverse Mode | TEM00 |
| Beam Divergence, Full Angle (mrad) | <1.5 |
| Beam Diameter at the Aperture (1/e², mm) | <2 |
| Polarization Ratio | >100:1, Horizontal (Vertical optional) |
| Cooled Method | Air cooled |
| Operating Temperature (℃) | 15-35 |
| Power Supply (100-240VAC) | PSU-FS |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # FS-H-780A
Please request a quotation for a real price and lead time.
