HPL-1064-CW 1064 nm Water Cooling High Power LD Pumped All-Solid-State Laser
$1,000,000.00
Description: All solid state high power CW laser at 1064 nm with ultra compact, long lifetime, low cost and easy operation.
Applications: scientific experiment, optical instrument, optical sensor, measurement, spectrum analysis, etc.
Model #: HPL-1064-CW
| Wavelength (nm) | 1064±1 |
| Operating Mode | CW |
| Power (W) | 100, 150, 200, 300, 400, 500 |
| Average Power Stability (rms, 4 hours ± 3°C) | <3%, <2%, <1% |
| Transverse Mode | Multimode |
| M2 | <5 |
| Beam Divergence, Full Angle (mrad) | <2 |
| Beam Diameter at the Aperture (mm) | ~4 |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Water cooled |
| Operating Temperature (°C) | 10-35 |
| Power Supply (380 VAC) | 3-Phase |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # HPL-1064-CW
Please request a quotation for a real price and lead time.
