HPL-1064-QM 1064 nm Ultra High Power LD Pumped All-Solid-State AOM Q-Switched Laser
$1,000,000.00
Description: Ultra high power all solid state AOM Q-switched laser at 1064 nm with high peak power and short pulse duration.
Applications: marking, carving, measurement, research and so on
Model #: HPL-1064-QM
| Wavelength (nm) | 1064±1 |
| Operating Mode | Q-switched: AOM (Acousto-Optic Modulation) |
| Single Pulse Energy (mJ) | 5-10 |
| Pulse Duration (ns) | ~85 |
| Average Power (W) | 100-300 |
| Rep. Rate (kHz) | 1-10 |
| Peak Power (MW) | 0.05-0.1 |
| Power Stability (rms, 4 hours ± 3°C) | <3%, <2% |
| Beam Divergence, Full Angle (mrad) | <2 |
| Beam Diameter at the Aperture (mm) | ~2 |
| M2 | <1.3 |
| Beam Height from Base Plate (mm) | 80 |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Air cooled |
| Operating Temperature (°C) | 10-35 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # HPL-1064-QM
Please request a quotation for a real price and lead time.
