HPL-1319-CW 1319 nm Water Cooling High Power LD Pumped All-Solid-State CW Laser
$1,000,000.00
Description: All-solid-state CW infrared laser at 1319 nm featuring ultra compact, long lifetime, low cost and easy operation.
Applications: scientific experiment, optical instrument, optical sensor, measurement, spectrum analysis
Model #: HPL-1319-CW
| Wavelength (nm) | 1319±1 |
| Operating Mode | CW |
| Output Power (W) | 20-50, 50-150, 150-220 |
| Average Power Stability (rms, 4 hours ± 3°C) | <5%, <3% |
| Beam Divergence, Full Angle (mrad) | <3.5 |
| Beam Diameter at the Aperture (1/e2, mm) | <12 |
| Beam Height from Base Plate (mm) | 55 |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Water cooled |
| Operating Temperature (°C) | 15-35 |
| Power Supply (220-240 VAC) | PSU-HPL-CW |
| Expected Lifetime (hours) | >10000 |
| Pilot Light (optional) | 5 mW @650 nm (optional) |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # HPL-1319-CW
Please request a quotation for a real price and lead time.
