HPL-1319-QM 1319 nm Ultra High Power LD Pumped All-Solid-State Q-Switched Laser
$1,000,000.00
Description: All-solid-state Q-switched infrared laser at 1319 nm featuring high peak power, high repetition rate and short pulse duration.
Applications: marking, carving, measurement, scientific research
Model #: HPL-1319-QM
| Wavelength (nm) | 1319±1 |
| Operating Mode | Actively Q-switched |
| Average Power (W) | 50-100 @10 kHz |
| Pulse Duration (ns) | ~250 @10 kHz & 100 W |
| Repetition Rate (kHz) | 10-20 |
| Single Pulse Energy (mJ) | 5-10 |
| Peak Power (kW) | 20-40 @10 kHz |
| Average Power Stability (rms, 4 hours ± 3°C) | <5%, <3% |
| Beam Divergence, Full Angle (mrad) | <3.5 |
| Beam Diameter at the Aperture (1/e2, mm) | <15 |
| Beam Height from Base Plate (mm) | 60 |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Water cooled |
| Operating Temperature (°C) | 15-35 |
| Power Supply (220-240 VAC) | PSU-HPL-Q & PSU-HPL-CW |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # HPL-1319-QM
Please request a quotation for a real price and lead time.
