HPL-MIR-3900 3900 nm High Power Mid-Infrared Laser
$1,000,000.00
Description: Water-cooled LD pumped all-solid-state 3-5 µm mid-IR laser featuring high power, high repetition rate and short pulse duration, widely used in defense, remote sensing, civilian applications and counter-measures against infrared sensors.
Applications: defense, remote sensing, civilian applications, systems for counter-measures against infrared sensors
Model #: HPL-MIR-3900
| Wavelength (nm) | 3900 |
| Spectral Width (nm) | 250 |
| Operating Mode | Actively Q-switched |
| Average Power (W) | 0.1-1 |
| Pulse Duration (ns) | ~20 |
| Repetition Rate (kHz) | 10 |
| Single Pulse Energy (mJ) | 0.1 @ 10 kHz & 1 W |
| Power Stability (rms, 4 hours ± 3°C) | <10%, <5% |
| Beam Divergence, Full Angle (mrad) | <5 |
| Beam Diameter at the Aperture (1/e2, mm) | <6 |
| Beam Height from Base Plate (mm) | 60 |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Water Cooled |
| Operating Temperature (°C) | 15-35 |
| Power Supply (100-240 VAC) | PSU-MIR (3U) |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # HPL-MIR-3900
Please request a quotation for a real price and lead time.
