LPS-1064-L 1064 nm High Energy Lamp Pumped Solid State Q-Switched Laser
$1,000,000.00
Description: High energy lamp pumped solid state Q-switched laser at 1064 nm with high single pulse energy, short pulse duration and high peak power.
Applications: LIF, LIBS, ICP-MS, Raman, scientific research, and so on
Model #: LPS-1064-L
| Wavelength (nm) | 1064±1 |
| Operating Mode | Actively |
| Single Pulse Energy (mJ) | 300-500 / 500-1000 |
| Pulse Duration (ns) | <10 / <8 |
| Jitter (ns, sdev) | <1 (Int.) |
| Rep. Rate | 1-10 Hz (adjustable), single shot (optional) |
| Energy Stability (std dev/mean) | <2%, <1%, (<0.5% optional) |
| Beam Divergence, Full Angle (mrad) | ~1 / <3 |
| Beam Diameter (mm) | ~7 / ~9 |
| Warm-up Time (minutes) | <15 |
| Beam Height from Base Plate (mm) | 80 |
| Cooled Method | Water cooled |
| Operating Temperature (℃) | 15-30 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # LPS-1064-L
Please request a quotation for a real price and lead time.
