LPS-1064-M 1064 nm Lamp Pumped Solid State Long Pulsed Laser
$1,000,000.00
Description: Lamp pumped solid state long pulsed laser at 1064 nm with high signal pulse energy, high repetition rate and long pulse duration.
Applications: laser processing, scientific research, and so on
Model #: LPS-1064-M
| Wavelength (nm) | 1064±1 |
| Operating Mode | Actively |
| Single Pulse Energy (J) | 1-5 @5 ms / 5-10 @5 ms |
| Pulse Duration (ms) | 0.1-20 |
| Rep. Rate | 1-10 Hz (adjustable), single shot (optional) |
| Energy Stability (std dev/mean) | <3%, <2% |
| Beam Divergence, Full Angle (mrad) | <5 |
| Beam Diameter (mm) | ~6 |
| Warm-up Time (minutes) | <15 |
| Cooled Method | Water cooled |
| Operating Temperature (℃) | 15-30 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # LPS-1064-M
Please request a quotation for a real price and lead time.
