LPS-1064-PS 1064 nm High Energy Diode and Lamp Pumped Solid State Laser
$1,000,000.00
Description: High energy diode and lamp pumped solid state laser at 1064 nm with high single pulse energy, short pulse duration and high peak power.
Applications: PIV, LIF, LIBS, ICP-MS, Raman, scientific research, and so on
Model #: LPS-1064-PS
| Wavelength (nm) | 1064±1 |
| Operating Mode | Actively |
| Single Pulse Energy (mJ) | >100 |
| Pulse Duration (ps) | <30 |
| Rep. Rate (Hz) | 1-10 |
| Energy Stability (std dev/mean) | <3% |
| Beam Divergence, Full Angle (mrad) | <3 |
| Beam Diameter (mm) | ~12 |
| Polarization | Vertical |
| Warm-up Time (minutes) | <60 |
| Beam Height from Base Plate (mm) | 200 |
| Cooled Method | Water cooled |
| Operating Temperature (℃) | 15-30 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # LPS-1064-PS
Please request a quotation for a real price and lead time.
