LPS-S-1064 1064 nm High Energy Lamp Pumped Solid State Q-Switched Laser
$1,000,000.00
Description: High energy lamp pumped solid state Q-switched laser at 1064 nm with high single pulse energy, short pulse duration and high peak power.
Applications: PIV, LIF, LIBS, ICP-MS, Raman, scientific research, military, and so on
Model #: LPS-S-1064
| Wavelength (nm) | 1064±1 |
| Operating Mode | Q-switched: EOM (Electro-optic modulation) |
| Single Pulse Energy (mJ) | 50 / 100 / 200 / 300 |
| Pulse Duration (ns) | <10 / <10 / <8 / <8 |
| Rep. Rate (Hz) | 1-10 (adjustable) |
| Energy Stability | <3% |
| Beam Divergence, Full Angle (mrad) | ~1 / ~1 / ~1 / ~3 |
| Beam Diameter (mm) | ~6 |
| Warm-up Time (minutes) | <15 |
| Cooled Method | Water cooled |
| Operating Temperature (℃) | 15-30 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # LPS-S-1064
Please request a quotation for a real price and lead time.
