MDL-III-1290DFB-SM 1290 nm Single Mode Fiber Output DFB Diode Laser
$1,000,000.00
Description: DFB (distributed feedback) diode laser at 1290 nm with single mode fiber output, featuring ultra compact design, long lifetime and narrow spectral linewidth.
Applications: gas detection, measurement, communication, spectroscopy
Model #: MDL-III-1290DFB-SM
| Central Wavelength (nm) | 1290±3 |
| Operating Mode | CW |
| Output Power After Fiber (mW) | 1-15 |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1%, <0.5% |
| Fiber Type | SM fiber, PM fiber optional |
| Fiber Core Diameter | ~5 µm |
| Fiber Connector | FC/APC |
| Fiber Length | 1 m (other lengths can be customized) |
| Fiber Jacket | PVC |
| Transverse Mode | TEM00 |
| Ellipticity | >0.95 |
| M2 After Fiber | ~1.1 |
| Warm-up Time (minutes) | <5 |
| Cooled Method | Conduction |
| Operating Temperature (°C) | 10-35 |
| Power Supply (100-240 VAC) | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM |
| Modulation Option | DC-1 kHz, 1 kHz-10 kHz, 10 kHz-30 kHz optional; TTL and Analog optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MDL-III-1290DFB-SM
Please request a quotation for a real price and lead time.
