MDL-III-1450R 1450 nm Round Beam Infrared Diode Laser
$1,000,000.00
Description: Infrared diode laser at 1450 nm with round beam, ultra compact design, long lifetime, cost-effectiveness and easy operation.
Applications: measurement, communication, spectrum analysis, etc.
Model #: MDL-III-1450R
| Central Wavelength (nm) | 1450±15 |
| Operating Mode | CW |
| Output Power (mW) | 1-150 / 150-200 |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1%, <0.5% |
| Transverse Mode | Round |
| Dimensions of Beam at the Aperture (mm) | ~2 |
| Beam Divergence, Full Angle (mrad) | ~10 (1-150 mW) / ~20 (150-200 mW) |
| Warm-up Time (minutes) | <5 |
| Beam Height from Base Plate (mm) | 24.8 |
| Operating Temperature (°C) | 10-35 |
| Power Supply (100-240 VAC) | PSU-III-FDA/PSU-III-LED/PSU-A-D |
| Modulation Option | DC-1 kHz, 1 kHz-10 kHz, 10 kHz-30 kHz, 30 kHz-100 kHz optional; TTL and Analog optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MDL-III-1450R
Please request a quotation for a real price and lead time.
