445 nm LD Pumped All-Solid-State CW UV Laser MDL-III-445
$1,000,000.00
Description: It features ultra compact design, long lifetime, cost-effectiveness and easy operation.
Applications: medical imaging, flow cytometry, DNA sequencing
Model #: MDL-III-445
| Model | MDL-III-445 |
| Wavelength | 445 nm |
| Operating mode | CW |
| Output power (mW)¹ | >1, 50,…, 500 / >500, 600,…, 1000 |
| Power stability (rms, over 4 hours) | <3%, <2%, <1%, <0.5% |
| Transverse mode | Multimode |
| Beam diameter at the aperture (1/e², mm) | <2.5×5.2 / <2×5 |
| Beam divergence, full angle (mrad) | <2.1×1.6 / <2.5×0.2 |
| Polarization ratio | >50:1 (>100:1 optional) Horizontal±5 degree (Vertical optional) |
| Warm-up time (minutes) | <5 |
| Cooled method | Conduction |
| Beam height from base plate (mm) | 24.8 |
| Operating temperature (℃) | 10-35 |
| Power supply (100-240VAC) | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM |
| Expected lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MDL-III-445
Please request a quotation for a real price and lead time.
