MDL-III-850-SLD-SM 850 nm Single Mode Fiber Output Super Luminescent Diode Laser
$1,000,000.00
Description: Super luminescent diode (SLD) at 850 nm with single mode fiber output, featuring wide spectral linewidth, short coherent length, long lifetime and easy operation.
Applications: medical treatment, machine vision, metrology, fiber optic current sensing, etc.
Model #: MDL-III-850-SLD-SM
| Central Wavelength (nm) | 850±20 |
| Spectral Line Width (nm) | ~35 |
| Operating Mode | CW |
| Output Power After Fiber (mW) | 1-4 |
| Power Stability (rms, 4 hours ± 3°C) | <2%, <1%, <0.5% |
| Fiber Type | SM fiber, PM fiber optional |
| Fiber Core Diameter | 4-9 µm, 0.12 NA |
| Fiber Connector | FC/PC, FC/APC optional |
| Fiber Length | 1 m (other lengths can be customized) |
| Fiber Jacket | Metal, PVC optional |
| Transverse Mode | TEM00 |
| Ellipticity | >0.95 |
| M2 After Fiber | ~1.1 |
| Warm-up Time (minutes) | <5 |
| Cooled Method | Conduction |
| Operating Temperature (°C) | 10-35 |
| Power Supply (100-240 VAC) | PSU-III-FDA/PSU-III-LED/PSU-A-D/PSU-III-OEM |
| Modulation Option | DC-1 kHz, 1 kHz-10 kHz, 10 kHz-30 kHz, 30 kHz-100 kHz optional; TTL and Analog optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MDL-III-850-SLD-SM
Please request a quotation for a real price and lead time.
