MDL-III-P-1550 1550 nm Infrared Diode Laser
$1,000,000.00
Description:
Applications: microelectronics, material processing, solar energy and medical equipment manufacturing
Model #: MDL-III-P-1550
| Model | MDL-III-P-1550 |
| Central wavelength (nm) | 1550±10 |
| Operating mode | Modulation (Pulse) |
| Output power (mW) | >1, 2, 3,…, 15 |
| Transverse mode | Multimode Dimensions of beam at the aperture (1/e2,mm) ~3. 5 |
| Beam divergence, full angle (mrad) | <16 Single pulse energy (μJ) ~2.3 (@6kHz) |
| Pulse duration (ns) | ~150 (@6kHz) |
| Peak power (W) | ~15.3 (@6kHz) |
| Rep. rate | 1~6 |
| Warm-up time (minutes) | <5 |
| Beam height from base plate (mm) | 27.4 |
| Operating temperature | 10~35 |
| Power supply | PSU-A-D |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MDL-III-P-1550
Please request a quotation for a real price and lead time.
