MDL-MD-405 405 nm LD Pumped All-Solid-State CW UV Laser
$1,000,000.00
Description: It features ultra compact design, long lifetime, cost-effectiveness and easy operation.
Applications: laser projection, laser shows, biomedical applications, holography, metrology
Model #: MDL-MD-405
| Model | MDL-MD-405 |
| Central Wavelength (nm) | 405±5 |
| Operating Mode | CW |
| Output Power (mW)¹ | 1-2000 / 2000-4000 |
| Power Stability (rms, 4 hours ±3°C) | <2%, <1%, <0.5% |
| Transverse Mode | Multimode |
| Polarization Direction | Horizontal + Vertical / Horizontal / Vertical |
| Beam Diameter at the Aperture (mm) | ~3.0×4.0 / ~4.0×4.0 |
| Beam Divergence, Full Angle (mrad) | ~2.8×0.5 / ~4.3×0.5 |
| Warm-Up Time (minutes) | <5 |
| Beam Height from Base Plate (mm) | 25 |
| Operating Temperature (℃) | 25±3 |
| Power Supply (100-240VAC) | PSU-H-FDA/PSU-H-LED/PSU-N-LED |
| Modulation Option | DC-1kHz, 1kHz-10kHz, 10kHz-30kHz optional; TTL and Analog optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MDL-MD-405
Please request a quotation for a real price and lead time.
