MGL-FN-577-A 577 nm LD Pumped All-Solid-State Yellow Laser
$1,000,000.00
Description: All solid-state CW mode laser is made features of ultra compact, easy operating, high power and stability.
Applications: flow cytometry, spectrum analysis, microscopy, semiconductor inspection, cell sorting, optical instrument, physics experiment
Model #: MGL-FN-577-A
| Model | MGL-FN-577-A |
| Wavelength (nm) | 577±1 |
| Operating Mode | CW |
| Output Power (W)¹ | 1.2-4 |
| Power Stability (rms, 4 hours ±3°C) | <5%, <3% |
| Transverse Mode | TEMn1 |
| M² | <1.5 |
| Beam Diameter at the Aperture (1/e², mm) | <1.4 |
| Beam Divergence (mrad) | <10 |
| Polarization Ratio | >100:1, Horizontal (Vertical optional) |
| Beam Height from Base Plate (mm) | 27.4 |
| Operating Temperature (℃) | 10-35 |
| Operating Voltage | 100-240V |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MGL-FN-577-A
Please request a quotation for a real price and lead time.
