MGL-U-505-SF 505 nm LD Pumped All-Solid-State Single Frequency Green Laser
$1,000,000.00
Description: All solid-state CW mode laser is made features of ultra compact, easy operating, high power and stability.
Applications: flow cytometry, spectrum analysis, microscopy, semiconductor inspection, cell sorting, optical instrument, physics experiment
Model #: MGL-U-505-SF
| Model | MGL-U-505-SF |
| Wavelength (nm) | 505±1 |
| Operating Mode | CW |
| Output Power (mW)¹ | 1-200 |
| Power Stability (rms, 4 hours ±3°C) | <3%, <2%, (<1% optional @ Water Cooled) |
| Transverse Mode | TEM00 |
| M² | ~3.0 |
| Beam Diameter at the Aperture (1/e², mm) | ~3.0 |
| Beam Divergence (mrad) | <3.0 |
| Cooled Method | Air cooled / Water cooled |
| Warm-Up Time (minutes) | <10 |
| Beam Height from Base Plate (mm) | 108 @ Air Cooled / 61.5 @ Water Cooled |
| Power Supply (100-240VAC) | PSU-SF |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MGL-U-505-SF
Please request a quotation for a real price and lead time.
