MIL-T-1064-SM 1064 nm Single Mode Fiber Output LD Pumped All-Solid-State Infrared Laser
$1,000,000.00
Description: All solid state infrared laser at 1064 nm with single mode fiber output, featuring ultra compact design, long lifetime and ease of operation.
Applications: scientific experiments, optical instrumentation, optical sensing, measurement, communication, and spectral analysis
Model #: MIL-T-1064-SM
| Part Number | MIL-T-1064-SM |
| Wavelength (nm) | 1064±1 |
| Operating Mode | CW |
| Output Power (W) | 1-5 |
| Power Stability (rms, over 4 hours) | <3%, <2%, <1% (optional) |
| Transverse Mode | TEM00 (single mode fiber output) |
| M2 | <1.1 |
| Fiber Numerical Aperture | 0.10-0.12 |
| Polarization Ratio | >50:1 after PM fiber (optional) |
| Fiber Type | SM fiber (PM fiber optional) |
| Fiber Connector | FC/APC |
| Fiber Jacket | PVC |
| Fiber Length | 1 m (other lengths can be customized) |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Air cooled |
| Operating Temperature (℃) | 10-30 |
| Power Supply (100-240 VAC) | PSU-W-LED/PSU-W-FDA |
| Modulation Option | DC-1 kHz, 1 kHz-10 kHz, 10 kHz-30 kHz, 30 kHz-100 kHz optional; TTL and Analog optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MIL-T-1064-SM
Please request a quotation for a real price and lead time.
