MIL-W-1319A 1319 nm Ultra High Power LD Pumped All-Solid-State Laser
$1,000,000.00
Description: All-solid-state infrared laser at 1319 nm featuring ultra-compact design, long lifetime, low cost and easy operation.
Applications: scientific experiment, optical instrument, optical sensor, measurement, spectrum analysis
Model #: MIL-W-1319A
| Wavelength (nm) | 1319±2 |
| Operating Mode | CW |
| Output Power (W) | 5-10 |
| Power Stability (rms, 4 hours ± 3°C) | <3%, <2%, (<1% optional) |
| Transverse Mode | Near TEM00 |
| Beam Divergence, Full Angle (mrad) | <1.0 |
| Beam Diameter at the Aperture (1/e2, mm) | ~4 |
| Warm-up Time (minutes) | <10 |
| Pointing Stability (µrad) (over 2 hours after warm-up and ±3°C) | <50 |
| Pointing Stability Over Temperature (µrad/°C) | <20 |
| Polarization Ratio | >50:1 (100:1 optional), Horizontal (Vertical optional) |
| Beam Height from Base Plate (mm) | 80 |
| Operating Temperature (°C) | 10-35 |
| Power Supply (100-240 VAC) | PSU-W-LED |
| Modulation Option | DC-1 kHz, 1 kHz-10 kHz, 10 kHz-30 kHz optional; TTL and Analog optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MIL-W-1319A
Please request a quotation for a real price and lead time.
