MIL-W-1834 1834 nm All-Solid-State Infrared Laser
$1,000,000.00
Description: LD pumped all-solid-state 1834 nm infrared laser featuring high power, good beam quality and easy operation.
Applications: material processing (especially plastics), pumping of mid-infrared laser sources, medical procedures such as precise tissue ablation, ophthalmic surgery and dentistry
Model #: MIL-W-1834
| Wavelength (nm) | 1834±2 |
| Operating Mode | CW |
| Output Power (mW) | 1-1300 |
| Power Stability (rms, 4 hours ± 3°C) | <5%, <3% |
| Transverse Mode | Near TEM00 |
| M² | <3.0 |
| Beam Divergence, Full Angle (mrad) | <2.0 |
| Beam Diameter at the Aperture (1/e2, mm) | <2.0 |
| Beam Height from Base Plate (mm) | 98 |
| Warm-up Time (minutes) | <10 |
| Cooled Method | Air Cooled |
| Operating Temperature (°C) | 10-35 |
| Power Supply (100-240 VAC) | PSU-W-LED or PSU-W-FDA |
| TTL/Analog Modulation | TTL or Analog with 1 Hz-1 kHz, 1 kHz-10 kHz, 10 kHz-30 kHz optional |
| Expected Lifetime (hours) | >10000 |
Please refer to the Data Sheet for detailed specifications
If you need a different model number, please feel free to ask for a quotation.
- Long lifetime
- FDA registered
- ISO and CE qualified
- ROHS complied
- Model # MIL-W-1834
Please request a quotation for a real price and lead time.
